Type

KWM 169D

KWM 209D

Displacement Volume (cc.)

163

196

Bore x Stroke(mm .X. mm.)

68 x 45

68 x 54

Max. Horse Power

5.5 HP/ 3,600 rpm

6.5HP / 3,600 rpm

Max.Torque (kg.m / rpm)

1.1 / 2,500

1.35 / 2,500

Compression Ratio

8.5 : 1

8.5 : 1

Min. Specific Fuel Consumption Ratio (g/hp/hr)

230

230

Cooling System

Air Cooling

Lgnition

Flywheel Magneto Transistor

Spark Plug

BOSCH W6DC,NGK BP6ES

Carburator

Float Type with Fixed Main jet

Air Cleaner

Oil bath type

Lubrication

Splash System

Oil

SAE 40 GRADE SJ ,SG, SF

Oil Capacity (Liters)

0.6

0.6

Starter System

Recoil Start With Automatic Compression Release

Fuel

Unleaded Gasoline

Fuel Capacity (Liter)

3.6

3.6

Output Shaft

Straight Shaft Diameter 19.05 mm.Keyway and internal thread 5/16-24UNF

Dimension Wx Lx H (mm)

392 x 325 x 320

Net Weight (kg)

15

16
